Features:
Toughened glass panel
Precise temperature calibration function
Black/White panel can be optional
Free selection of Auto/ Manual mode
Easily steel frame back plate installation
Intelligent control the on/off of fan-coil, electrical ball valve or air valve
Wired Communication: RS485 (Optional)
Wireless Communication: WiFi (Optional)
Specifications:
Power Supply: AC85V~AC260V / AC24V 50/60Hz
Self Consumption: < 1W
Display Temperature: ±0.5℃
Temperature Setting: 0~99 ℃(Adjustable)
Button Way: Capacitive touch button
Outer Shell: Toughened glass and PC+ alloy
Dimensions: 86* 86*14mm
Hole Pitch: 60-65mm(Standard 86 box)
Load Current: 2 A(Resistive),1 A(Perceptive)
Working Environment: 0~50℃; <95% RH(Non-condensation)
